REL S3 Subwoofer





S3
Rel S3 is a 350 watt front-firing active subwoofer with down-firing passive radiator and Next Gen II Class D Amplification. The Rel S3 incorporates Longbow wireless receiver technology that uses no digital compression, giving a performance that rivals competitors's hard-wired models, REL claims. The wireless receiver is built in as standard, wireless capability is achieved via the optional matching Longbow transmitter which has a range of 15 metres. The Serie S3 uses long-throw bass engines that are said to be super lightweight for speed and slam. Superalloy drivers feature a seamless one-piece aerospace grade" T-6063 alloy cone structure. Additional cabinet bracing throughout the range delivers quieter, more dynamic bass.

Specifications
- Type: Front-firing active woofer, down-firing passive radiator
- Active Drive Unit: 10 in., 250mm long-throw, die cast Aluminium chassis
- Passive Radiator: 12 in., 300mm
- Lower Frequency Response in Room: 22Hz at -6 dB
- Input Connectors: Hi Level Neutrik Speakon, Left and Right Lo Level phono, LFE phono, SMA
  connector for wireless antenna
- Gain Control Range: 80 dB
- Power Output: 350 watts (RMS)
- Phase Switch: Yes, 0 or 180 degrees
- Amplifier Type: Next Gen II Class D

Freedom: LongBow™ Wireless Connectivity
LongBow permits very fast, uncompressed bass to be sent wirelessly within the same room approximately 45 feet (somewhat dependent upon room clutter). We have selected an un compressed format as it results in natural, quick delivery compared with conventional wi-fi or Bluetooth systems. Because it is a REL, we developed LongBow with both high level (or low level with crossover intact) AND .1 channel delivery so that REL Theatre Reference performance can be maintained even when using our wireless delivery system.

Protection System
- Fully Electronic with SET-SAFE: Yes
- D.C. Fault: Yes
- Output Short: Yes
- Mains Input Voltage: 220-240 volts, 110-120 volts for certain markets
- Fuses: 5 Amp semi delay 220 volts operation
- 9 Amp semi delay 120 volts operation

Dimensions
- W x H x D, Including Feet and Rear Panel Controls: 406 x 424 x 463.5 mm
- 1.75in (44.5mm) in depth when using Hi Level connector
- Net Weight: 61.4 lbs. (27.85 kg)
- Shipping Weight: 71 lbs. (32.2 kg)
- Finish Gloss Piano Black or Gloss White Lacquer
